Touchscreen-operated for multi-layer stripping and cutting of flexible coaxial cables, wires, cables, tubes, and various PVC, rubber, Teflon, and nylon materials.
Key Features • Durable design
• Multi-material guides
• Easy programming,
• Fast transport
• All-electric operation
• Low power use
• HMI ( Touch Screen)
Technical Specifications
Technical Parameters
Specifications
Operating interphase
HMI ( Touch Screen)
Wire Type
Coaxial Cable
Minimum cable outer dia
3 mm
Maximum cable outer dia
25 mm
Stripping Layers
9 Layers Max
Stripping length
1 mm to 250 mm
Clamping
Motor driven with programmable clamping force
Noise Level
< 70 db
Air supply
4.0 – 6.0 bar Dried and filtered air
Power
800 Watts
Power Supply
230 to 240V (50/60 Hz)
Function mode
Foot Pedal, push button
Drive Mode
DC servo motor/ TBI ball screw
Dimensions (L x W x H)
1200mm x 225mm x 400 mm
Net Weight
55 kg
Output Range (approx)
700 – 1200 pcs/ h (depending on operator skill)
Length Accuracy
±0.2MM ( L x 0.04%) Depends on the materials
