Foot-pedal–controlled wire stripping machine designed for precise, efficient operation with adjustable stripping and cutting parameters. Durable, lightweight construction supports long shifts and easy portability, making it well-suited for both single-core and multi-core cables.
Key Features
• Pneumatic Wire Stripper – Compact and portable automatic machine, ideal for stripping multi-conductor, PVC, solid core, single-stranded, computer, telephone, and flat wires.
Technical Specifications
Parameter
Specification
Operating interphase
HMI ( Touch Screen)
Wire Type
Pvc, Solid Core, Single Standed & Rubber wires
Minimum cable size
0.2 sqmm
Maximum cable size
4.0 sq mm
Maximum Stripping length
20.0 mm
Length Accuracy
±0.2MM ( L x 0.04%) Depends on the materials
Noise Level
< 70 db
Air supply
6.0 bar Dried and filtered air
Power Supply
230 to 240V (50/60 Hz)
Cylinder Stroke
20 mm
Dimensions (L x W x H)
260 x 150 x 270 mm
Net Weight
9.5 kg
Output Range (approx)
1500 - 2000 numbers per hour (depending on operator skill)
