High-performance, servo-driven press with adjustable stroke, micron-level accuracy, low noise, and versatile applicator compatibility for precise, flexible crimping.
Key Features
• Servo-driven control
• Micron-level crimp height adjustment
• Configurable stroke
• Sequence crimping
• Wide applicator compatibility
• Multiple modes
• Low noise
• High stability
Technical Specifications
|
Technical Parameters
|
Specifications
|
|
Power Input
|
Single Phase 220 V AC 50 Hz
|
|
Motor (kW)
|
2
|
|
Control
|
Electronic
|
|
Tonnage (Ton)
|
10
|
|
Terminal Sheet Thickness (mm)
|
3
|
|
Wire Size (Sq. mm)
|
35
|
|
Stroke
|
Adjustable
|
|
Shut Height
|
135.78 / 160 / 190 mm
|
|
Weight (Kg)
|
480
|
|
Dimension (L × B × H) (mm)
|
650 × 730 × 1000
|
